FEATURES

*Measure moisture content over range 9% to 30%

*Heavy duty & compact housing case, designed for easy carry out & operation.

* 9 material species group in memory,  calibrations for about 150 different species of wood/timber are provide.

* Records Maximum & Minimum reading with recall.

* Built-in self-calibration circuit.

* Data hold function to freeze the desired value on display.

*0 to 50℃ manual temp. compensation setting.

* Auto shut off saves battery life.

* Microprocessor circuit assures maximum possible accuracy, provides special functions and features.

* Built-in low battery indicator.

* Super large LCD with dual display

* Separate pin type moisture probe, easy

GENERAL SPECIFICATIONS

Applications

For surveying buildings for dampness and for the rapid determination of the moisture content of wood/timber

Principal

Used the 2 pins electrode to measure the conductive ability of the species, then converter to the reading of % " Moisture of Content

Default Memory for the species

9 material species groups in memory, calibrations for about 150 different species of wood are provided

Circuit

Custom one-chip of microprocessor LSI circuit

Display

13 mm ( 0.5" ) super large LCD display, dual function meter's display

Measurement

Measure moisture content over range 9 % to 30 %.

Probe

Separate 2 pins moisture electrode

Temperature Compensation

Manual temperature compensation of the meter in the range of 0 to 50℃ .

Calibration

Built-in self-calibration circuit by push button on front panel.

Data Hold

By push button on front panel.

Memory Recall

Records Maximum & Minimum reading value.

Power off

Auto shut off, saves battery life, or manual off by push button

Sampling Time

Approx. 0.8 second

Operating Temperature

0 to 50℃.

Operating Humidity

Less than 80% R.H.

Power Supply

006P, MN1604 ( PP3 ) DC 9V battery or equivalent, recommend use the alkaline or heavy duty battery

Power Current

Approx. DC 6.5 mA.

Weight

330 g/0.73 LB

Dimension

Main instrument: 180 x 72 x 32 mm ( 7.1 x 2.8 x 1.3 inch ).

Moisture Probe: Round 23 mm Dia. x 165 mm. ( ROUND 0.9 inch Dia. X 6.5 inch )
